All Pumps › Vertical Openwell Submersible Pumps

F-Tech Engineering is leading Horizontal/Vertical Openwell submersible pump manufacturers in India.

Salient Features of Vertical Openwell Submersible Pumps
  • No suction problem: Pumpset works under water and hence suction problems do not arise.
  • No water level guard required: Due to horizontal construction, the pumpset will always remain submerged in water and therefore the pumps will never run dry, which is unique feature available only in this pumpset. Hence no water level guard is required.
  • Easy to install: Pumpset rest at the bottom of openwell and installation does not require foundation and pump house.
Application of Vertical Openwell Submersible Pumps
Vertical Openwell borewell submersible pump is designed for various applications like:
  • Sprinkler and drip irrigation systems.
  • Pumping from in-well bores.
  • Pumping from sumps for high rise buildings and industry.
  • River and canal lift-irrigation.
  • Openwell pumping for agriculture & irrigation.
Construction Features - Pumps
  • Compatible with low friction flexible hose pipes.
  • Optional bronze impeller on request.
  • Rigid cast iron impeller and volute casing provide good efficiency and long life.
Construction Features - Motor
  • Single and three phase water-filled submersible induction motor.
  • Heavy duty stainless steel motor body.
  • Heavy duty water-lubricated bearing for long trouble free operation.
  • Suitable for single phase 160-240 Vold and three phase 340-440 Vold, 50 Hz power supplies.
Warranty
  • All F-Tech Engineering products carries a 12 months manufacturing defects warranty from the date of purchase.
Construction of Materials Vertical Openwell Pumps
Name of Parts Material Used
Pump Shaft Stainless Steel 410
Bearing Bush Leaded Bronze
Diffuser Cast Iron / Stainless Steel
Impeller Cast Iron
Thurst Bearing SS Seagment & Teflon Thrust Plate
Casing Cast Iron
Housing Cast Iron
Pump Shell Stainless Steel 304
Stator Shell Stainless Steel
Operating Limitations Vertical Openwell Pumps
PARAMETERS Operating Range
H.P. Range 3.0 H.P. to 15.0 H.P. (Three Phase)
Head Range Upto 120 Meters
Discharge at Duty Point 250 to 800 LPM .
Maximum Discharge 1200 LPM
Operating Voltage 350 - 440 Volt
Maximum Temperature of Liquid 40° C
Maximum Permissible Amount Of Sand in Water 80 Grams/Cubic Meter
Maximum Voltage Fluctuation +15% -20% Maximum
Version Three Phase
From 2.25 kW to 9.0 kW, 415 Volt 50 Hz
# Due to continuous efforts in improvements, information furnished above is subject to change without notice
